Typhoon Short Ram Performance Air Intake System for the Mazda MX-5 (NB - 1.8L Engine)
Typhoon Short Ram Performance Air Intake System for the Mazda MX-5 (NB - 1.8L Engine)
Guaranteed to Increase Horsepower & Performance
Designed to improve throttle response and engine sound, this Performance Air Intake System replaces the entire restrictive factory intake system of your for your Mazda MX-5.
High-flow cotton media is designed to allow up to 50% more airflow than traditional paper filters — and greater airflow results in increased horsepower and torque. K&N® air filters are tested on a SuperFlow flow bench to ensure increased airflow over a stock filter. View testing data for many K&N filters on individual product pages.
Washable & Reusable
Unlike disposable filters which must be frequently replaced, K&N® High-Flow Air Filters™ are washable, reusable, and engineered to last for the life of your vehicle. Feel confident in your purchase with a 10-Year/Million Mile Limited Warranty.
Protect Your Engine
K&N’s state-of-the-art filter features thousands of microscopic cotton fibers, and an innovative design of layered, oiled cotton media helps to capture dirt and shield your engine from contaminants. Each filter design is tested in an ISO 5011 laboratory to ensure excellent filtration efficiency for outstanding engine protection.
Reduce Waste
Over 100 million disposable air filters and their packaging waste end up in landfills each year. Choosing a washable, reusable product that lasts for the lifespan of your vehicle helps to reduce unnecessary waste.
Detailed Information
Estimated Horsepower Gain | 3.58 HP @ 6499 RPM |
Replacement Filter | RU-4870 |
Air Filter Color | Red |
Air Filter Material | Cotton Gauze |
Air Filter Outlet Shape | Round |
Clamps Included | 5 |
Clamp Material | Stainless Steel |
Clamp Style | Regular |
Couplers Included | 3 |
System Type | Short-Ram Intake System |
Product Style | 69 Series Typhoon Kits |
Air Filter Height | 6.5 in (165 mm) |
Intake Pipe Color / Finish | Polished |
Intake Pipe Material | Aluminum |
CARB EO Number | D-269-37 |
Street Legal In All US States | See Vehicle Applications |
TUV Approved (Europe) | No |
Flange Inside Diameter | 2.75 in (70 mm) |
Flange Length | 2 in (51 mm) |
Flange Type | Centered |
Height | 6.5 in (165 mm) |
Base Outside Diameter | 6 in (152 mm) |
Top Outside Diameter | 5 in (127 mm) |
Top Style | X-Stream |
Top Material | None |
Weight | 6.9 lb (3.1 kg) |
Air Filter Large End Diameter | 6 in (152 mm) |
Product Box Height | 8.5 in (216 mm) |
Product Box Length | 18.25 in (464 mm) |
Product Box Width | 14.5 in (368 mm) |
Mounting Hardware Included | Yes |
Warranty | 1,000,000 Miles/10 Year |
